Specifications Main dimensions of the vessel are:
Premium Content
19 March 2008
| Loa (length overall) | 180.9 m |
| Lpp (length between perpendiculars) | 170.1 m |
| Beam | 46.2 m |
| Depth (moulded) | 16.1 m |
| Draft (operational) | 7.0-11.0 m |
| Installed power | 6 x 5,765 kW |
| The 5,000 tonne Heavy Lift Mast Crane is a typical and proven Huisman design, with the following main specifications: | |
| Capacity over the stern | 5,000 tonnes at 34 m |
| Capacity revolving | 4,000 tonnes at 41 m |
| Mast height | 82 m |
| Total boom length | 120 m |
| Max. reach main hoist | 79 m |
| Max. reach aux hoist | 109 m |
| Max. reach whip hoist | 122 m |
